Electrical Impedance Tomography

Next-generation medical imaging techniques

EIT creates real-time conductivity images by measuring surface voltage responses to applied currents - no radiation, portable, and cost-effective medical imaging technology.

Core Principles of EIT

Understanding the fundamental concepts behind electrical impedance tomography imaging

⚡

Current Injection

Safe alternating currents (10-100 kHz) are applied through surface electrodes to create measurable voltage distributions within the tissue.

📊

Voltage Measurement

Surface potential differences are measured at remaining electrodes with high precision to capture conductivity variations.

🧮

Forward Problem

Mathematical modeling predicts voltages for known conductivity distributions using finite element methods and Laplace's equation.

🔄

Inverse Reconstruction

Advanced algorithms reconstruct internal conductivity distributions from boundary voltage measurements through iterative optimization.

Medical Applications

Transforming healthcare with real-time, radiation-free imaging solutions

Electrical Impedance Tomography Device for Body Resistance-Based Imaging

Electrical Impedance Tomography (EIT) devices create images by measuring electrical resistance and capacitance inside the body. They are widely used in hospitals, especially in ICUs, respiratory care, and operating rooms, to monitor lung function in real time without invasive procedures.

95%
Accuracy
50 Hz
Update Rate

Real-Time Lung Function Monitoring in ICU, Respiratory, and Operating Rooms

These devices are primarily used in hospital intensive care units (ICUs), respiratory departments, and operating rooms. They provide real-time monitoring of lung function to support critical patient care.

88%
Accuracy
25 Hz
Update Rate

Brain Activity Imaging

Monitoring of neural activity and brain function changes through impedance variations in brain tissue.

82%
Accuracy
10 Hz
Update Rate

Research Teams & Experts

Leading institutions and researchers driving EIT innovation worldwide

Institution Icon

Wang, Kaidong

Founder, CTO

Ph.D. in Engineering from Tsinghua University, Research Scholar at Johns Hopkins Medical Center

Technology Strategy Technology Development Team Leadership
🏥

Hu, Guanzhong

CEO

Risk Control Manager in a Central State-Owned Financial Enterprise

Risk Control
⚗️

Liu, Changming

Algorithm Engineer

Software Development
🔬

Wang, Xiaopei

Hardware Engineer

Researcher at a Central State-Owned Enterprise

Hardware Design
🔬

Zhang, Ze

Software Engineer

Researcher at a Central State-Owned Enterprise

Software Design

Product Advantages

Comparing leading EIT solutions across key performance metrics

📱

Portable EIT

Sciospec

$100,000 USD
Resolution
Medium
Comfort
Low
User Experience
Low
🏥

Cart-based EIT

Draeger

$300,000 USD
Resolution
Low
Comfort
Medium
User Experience
Medium
⌚

Wearable EIT

Our Company

$5,000 Cost
Resolution
High
Comfort
High
User Experience
High
✓ 96% cost reduction
✓ Superior comfort & mobility
✓ Enhanced image quality
💡

Revolutionary Cost Efficiency

Our wearable EIT solution delivers premium performance at 96% lower cost than traditional systems, making advanced medical imaging accessible to healthcare providers worldwide.

🎯

Superior Patient Experience

Combining high resolution imaging with maximum comfort, our solution eliminates the trade-offs present in existing EIT systems.

Technical Deep Dive

Explore the advanced engineering and algorithms behind EIT systems

Linear Back Projection

Advantages
  • Fast computation (< 1ms)
  • Simple implementation
  • Real-time capable
  • Low memory requirements
Limitations
  • Low spatial resolution
  • Blurred boundaries
  • Linear approximation
  • Artifact prone

Gauss-Newton Method

Advantages
  • Higher accuracy
  • Better edge definition
  • Non-linear modeling
  • Regularization support
Limitations
  • Computationally intensive
  • Sensitive to noise
  • Convergence issues
  • Parameter tuning required

EIT vs Other Imaging Modalities

Understanding how EIT compares to traditional medical imaging technologies

Feature EIT CT Scan MRI Ultrasound
Radiation None ★ High dose None None
Portability Highly portable ★ Room-sized Room-sized Portable
Real-time Imaging 50+ fps ★ Limited Limited Real-time
Cost Low ★ Very high Very high Moderate
Spatial Resolution 5-10% body diameter Sub-millimeter ★ Sub-millimeter ★ 1-2mm
Functional Info Excellent ★ Limited Good Limited

EIT Research Evolution

Key milestones and future directions in electrical impedance tomography

1978

EIT Foundation

Barber & Brown develop the first EIT system at Sheffield University, establishing the theoretical framework.

🔬
1990s

Clinical Applications

First clinical trials in lung monitoring and gastric emptying studies demonstrate medical viability.

🏥
2010s

Algorithm Advances

Machine learning and advanced reconstruction algorithms significantly improve image quality and speed.

🤖
2025+

Future Horizons

AI-powered reconstruction, wearable EIT devices, and multi-frequency imaging promise revolutionary advances.

🚀

Ready to Explore EIT Further?

Download our comprehensive research guide covering implementation details, case studies, and the latest developments in electrical impedance tomography.
